LCR Meter

LCR Meter About

An LCR meter (Inductance (l), Capacitance (C), and Resistance (R)) is an instrument used to measure the inductance, capacitance, and resistance of a component, sensor or another device thats operation depends upon capacitance, inductance or resistance.

There are a variety of LCR meters from handheld to benchtop.

Handheld LCR meters have the advantage of being lightweight, portable and battery operated.

• Dual Backlit LCD display
• Auto LCR smart check and measurement
• SeriesParallel modes are selectable
• LsLpCsCp with DQ ESR parameters
• Support DCR mode 200002000M
• Five different test frequency are available 1001201k10k100k Hz
• Test AC signal level 06mVRMS typ
• Test range ex F1kHz
• L 20000 H 20000 H
• C 20000 pF 2000 Mf
• R 20000  2000 M
• Multilevel battery voltage detector
• Support Backlight  Buzzer sound driver
• Parameters displayed DC Resistance Serial Inductance Parallel Inductance Serial Capacitance Parallel Capacitance Serial Resistance Parallel Resistance Phase Angle Equivalence Serial Resistance Dissipation Factor Quality Factor
• Size H x W x D220mm x 96mm x 60mm
• Weight360g
